The mold base and cavities utilize premium 738H steel pre-hardened to HRC35-40, completely eliminating the need for post-machining heat treatment and preventing thermal distortion. The clean micro-structure of 738H steel allows high-gloss mirror polishing and precise texture etching, ensuring a flawless cosmetic appearance on the final molded part.
The mold processing parameters are tailored for ABS 704 LRP resin, a dedicated medical-grade plastic that ensures safe skin contact and strict regulatory compliance. ABS 704 LRP provides excellent chemical resistance, ensuring the finished ultrasound handle will not crack, discolor, or degrade when wiped down with aggressive hospital sanitizers.
Specifications
| Product Name | Medical Mold Precision Manufacture Injection Mold Medical Ultrasound Scanner Handle ABS 704 LRP |
| Mold Model | 25135 |
| Mould Base | LKM |
| Mould Material | s136 |
| Mold Precision | +/-0.01mm |
| Mould Life | 1 million shots |
| Mould Cavity | Single cavity |
| Runner System | cold/hot runner |
| Gate Type | Sub Gate |
| Equipment | High speed CNC, Standard CNC, EDM, Wire Cutting, WEDM, Grinder, Plastic Injection Molding Machine from 50-818T available. |
| Plastic Material | ABS 704 LRP |
| Metal Material | 738H HRC35-40 |
| Surface Treatment | Polishing |
| Pls Provide | 2D/3D drawing, samples |
| Quality System | ISO 9001: 2015 |
Applications
-
Point of Care Ultrasound (POCUS) Housing: Producing ergonomic, impact-resistant handles for handheld, portable ultrasound devices used in emergency rooms and ambulances.
-
Operating Room Diagnostic Units: Utilizing the chemical resistance of ABS 704 LRP to deploy handles that withstand aggressive, daily hospital-grade chemical sterilization and wipe-downs.
-
Intensive Care Ultrasound Systems: Applying the high dimensional stability of the 738H mold steel to ensure perfectly sealed handle joints, preventing fluid ingress (gel, blood, water) into the scanner electronics.
Advantages
- Medical Grade Biocompatibility: ABS 704 LRP meets strict healthcare requirements, ensuring the finished ultrasound scanner handle is non-toxic and completely safe for prolonged skin contact.
-
High Structural Integrity: Combining the core toughness of the HRC35-40 pre-hardened steel cavity with the rigid impact resistance of ABS 704 LRP yields a rugged, drop-proof ultrasound handle.
-
Excellent Surface Finish: The uniform micro-structure of 738H steel allows mirror-like polishing, resulting in a flawless, pore-free ABS handle surface that prevents bacteria accumulation.
-
Optimal Chemical Resistance: The molded ABS resin maintains its structural properties and aesthetic appearance even when exposed to harsh medical disinfectants and acoustic gels.
FAQ
Q:How about your quality control?
A:We have professional team to control mold quality, since we realize that quality control is the first priority to run business
Q:What's your lead time?
A:For most mold, 45 to 60 working days (not including Chinese official holidays) after deposit received and mold drawings approved
Q:How long can i get the sample?
A:Depends on your specific items,within 3-7 days is required generally.
Q:What information do you need to provide a mold quote?
A:3D part file (STEP/IGS), 2D drawing with tolerances, material type, estimated annual volume, and injection machine specifications (tonnage, tie-bar spacing).
